By GREE Canada

Free Match M Series - R32

Function: Heat Pump
Capacity: 18000 BTU
Free Match M Series

 FLEXIBILITY FOR YOUR COMFORT

Enjoy efficient whole-house comfort with highly versatile multi-zone systems that can
meet the comfort needs of everyone and every room in your home. The FREE MATCH M R32 series provides both cooling and heating in no fewer than f ive separate zones independently.

  • DURABLE, ROBUST CONSTRUCTION
    All FREE MATCH M R32 units are manufactured from heavy-gauge
    laminated steel and finished with a highly resistant powder coating. The
    anti-corrosion acrylic resin coating on the coils offers enhanced protection
    in corrosive environments, while improving hydrophilic properties
    and efficiency.



Key Features :

■ G20 Inverter Technology
■ Can Power Up To 5 Indoor Units
■ Multipoint Diagnostics
■ Automatic Restart in the Event of a Power Failure
■ Compact and Silent Design
■ Coil (Outdoor) : Copper Tube and Aluminum Fins with Anti-corrosion Coating (Gold Fins / 1500-hour Salt-water Spray)
■ Coil (Indoor) : Copper Tube and Aluminum Fins with Anti-corrosion Coating (Blue Fins / 500-hour Salt-water Spray)
■ Environmentally-friendly R32 Refrigerant

System Performance

Cooling Capacity

18,000 BTU/h

Heating Capacity

18,000 BTU/h

Power Input :

W

Power Input :

W

SEER 2 :

21.0

BTU/W*h

HSPF 2 :

10.0

BTU/W*h

EER 2 :

12.0

BTU/W*h

COP :

3.90

W/W

Indoor Unit Specifications

Moisture Removal Capacity :

L/h (pt/h)

Airflow Volume :

m³/h (CFM)

Sound Pressure Level :

dB(A)

Dimensions :

mm (in)

Weight (Net) :

kg (lb)

Weight (Gross) :

kg (lb)

Outdoor Unit Specifications

Ambient Temperature Range (Cooling) :

-30 to 48 (-22 to 118)

C° (F°)

Ambient Temperature Range (Heating) :

-30 to 24 (-22 to 75)

C° (F°)

Sound Pressure Level :

54

dB(A)

Dimensions :

822 x 550 x 352 (32-3/8 x 21-21/32 x 13-27/32)

mm (in)

Weight (Net) :

34.0 (75.0)

kg (lb)

Weight (Gross) :

37.0 (81.6)

kg (lb)
