By GREE Canada

Crossover Series - Wall-Mounted Kits

Function: Heat Pump
Capacity: 9000 BTU

FLEXIBILITY, EFFICIENCY, AND RELIABILITY AT YOUR SERVICE

The Crossover series is the first GREE product line that allows for single-zone residential
installation with various types of indoor units, offering a variety of solutions for your
home or office.

  • HEATING TO -30°C AND COOLING TO -29°C
    As one of the only heat pumps that can heat or cool at such extreme
    temperatures, the Crossover Series is designed to be your comfort ally in our cold
    comfort in our cold Canadian climates. It represents the ideal solution for your
    residential, commercial, or even server room applications.



Key Features :

■ G10 Inverter technology
■ Wi-Fi control
■ Precise airflow control
■ Low voltage start-up
■ Fins with anti-corrosion coating
■ Multiple fan speed
■ Adjustable LED display
■ Washable dust filters
■ Heavy gauge steel cabinet
■ Eco-friendly R410A refrigerant
■ Remote control (included)
■ Wired controller (in option)


Other possible combinations :

System Performance

Cooling Capacity

9,100 BTU/h (2,457 – 10,748)

Heating Capacity

11,000 BTU/h (2,593 – 13,307)

Power Input :

618

W

Power Input :

860

W

SEER 2 :

25.0

BTU/W*h

HSPF 2 :

9.5

BTU/W*h

EER 2 :

14.7

BTU/W*h

COP :

3.59

W/W

Indoor Unit Specifications

Moisture Removal Capacity :

0.80 (1.69)

L/h (pt/h)

Airflow Volume :

600/550/500/450/400/350/330 (353/324/294/265/235/206/194)

m³/h (CFM)

Sound Pressure Level :

40 / 37 / 35 / 32 / 29 / 26 / 25

dB(A)

Dimensions :

825 x 293 x 196 (32-1/2 x 11-1/2 x 7-11/16)

mm (in)

Weight (Net) :

9.5 (20.9)

kg (lb)

Weight (Gross) :

11.5 (25.4)

kg (lb)

Outdoor Unit Specifications

Ambient Temperature Range (Cooling) :

-29 to 50 (-20 to 122)

C° (F°)

Ambient Temperature Range (Heating) :

-30 to 30 (-22 to 86)

C° (F°)

Sound Pressure Level :

52

dB(A)

Dimensions :

848 x 596 x 320 (33-3/8 x 23-1/2 x 12-9/16)

mm (in)

Weight (Net) :

33.5 (73.9)

kg (lb)

Weight (Gross) :

36.5 (80.5)

kg (lb)
