By GREE Canada

Extreme Series

Function: Heat Pump
Capacity: 9000 BTU

THE ALL-NEW EXTREME, SIMPLY THE BEST

The Extreme Series offers advanced performance with an industry-leading efficiency
rating of 27 SEER2 in cooling operation and 11 HSPF2 in heating operation. Its quiet
design combined with its unmatched energy efficiency makes the Extreme the
ideal choice for any home or office.

  • SMART WIFI CONTROL
    Featuring built-in smart Wi-Fi, the Extreme allows you to operate your
    equipment via your cell phone or tablet from anywhere you have Wi-Fi access
    using the GREE+ app.



Key Features :

■ Ultra Heat technology
■ G10 Inverter technology
■ Energy Star ® certified
■ Wi-Fi control by mobile device (GREE+ ap)
■ Precise airflow control
■ Low voltage start-up
■ Vertical and horizontal swing louver control
■ Fins with anti-corrosion coating
■ Multiple fan speed
■ Adjustable LED display
■ Washable dust filters
■ Heavy gauge steel cabinet
■ Two-stage variable speed compressor
■ Eco-friendly R410A refrigerant
■ Remote control (included)
■ Wired controller (in option)

System Performance

Cooling Capacity

9,000 BTU/h (1,535 – 12,966)

Heating Capacity

9,000 BTU/h (2,388 – 13,648)

Power Input :

540 (50 – 1,400)

W

Power Input :

610 (200 – 1,500)

W

SEER 2 :

27.0

BTU/W*h

HSPF 2 :

11.0

BTU/W*h

EER 2 :

16.6

BTU/W*h

COP :

4.47

W/W

Indoor Unit Specifications

Moisture Removal Capacity :

0.80 (1.69)

L/h (pt/h)

Airflow Volume :

720/650/600/550/500/450/350 (424/383/353/324/294/265/206)

m³/h (CFM)

Sound Pressure Level :

46 / 40 / 38 / 36 / 33 / 31 / 19

dB(A)

Dimensions :

970 x 300 x 225 (38-3/16 x 11-13/16 x 8-55/64)

mm (in)

Weight (Net) :

13.5 (29.8)

kg (lb)

Weight (Gross) :

16.5 (36.4)

kg (lb)

Outdoor Unit Specifications

Ambient Temperature Range (Cooling) :

-18 to 54 (0 to 129)

C° (F°)

Ambient Temperature Range (Heating) :

-30 to 24 (-22 to 75)

C° (F°)

Sound Pressure Level :

53

dB(A)

Dimensions :

899 x 596 x 378 (35-3/8 x 23-1/2 x 14-7/8)

mm (in)

Weight (Net) :

45 (99.2)

kg (lb)

Weight (Gross) :

48 (105.8)

kg (lb)
