By GREE Canada

Rooftop Unit

Function: Heat Pump
Capacity: 24000 BTU

UNPARALLELED HEATING ENERGY EFFICIENCY

The Ultra-Heat rooftop heat pump adopts two-stage, two-cylinder compression and hot
gas injection technologies to achieve unprecedented heating performance at cold outside
temperatures.

  • UNIVERSAL CONTROL CONNECTION
    The GREE Rooftop heat pump allows two methods of temperature control: twowire
    communication without electrodes with the included GREE controller, and the
    standard 24 V connection. The communication distance between the controller
    and the heat pump can go up to 98.5 feet, so there’s no limit to how far you can
    control this high-efficiency heat pump.



Key Features :

■ Ultra Heat technology
■ G10 Inverter technology
■ Intelligent defrost technology
■ Standard 24 V communication
■ Auxiliary electric heater optional
■ Eco-friendly R410A refrigerant
■ Wired thermostat (included)

System Performance

Cooling Capacity

24,000 BTU/h

Heating Capacity

24,000 BTU/h

Power Input :

W

Power Input :

W

SEER 2 :

17.8

BTU/W*h

HSPF 2 :

8.8

BTU/W*h

EER 2 :

11.0

BTU/W*h

COP :

3.40

W/W

Indoor Unit Specifications

Moisture Removal Capacity :

L/h (pt/h)

Airflow Volume :

m³/h (CFM)

Sound Pressure Level :

dB(A)

Dimensions :

mm (in)

Weight (Net) :

kg (lb)

Weight (Gross) :

kg (lb)

Outdoor Unit Specifications

Ambient Temperature Range (Cooling) :

5 to 52 (41 to 125.6)

C° (F°)

Ambient Temperature Range (Heating) :

-30 to 24 (-22 to 75.2)

C° (F°)

Sound Pressure Level :

63

dB(A)

Dimensions :

1120 x 1250 x 900 (44 x 49-3/16 x 35-7/16)

mm (in)

Weight (Net) :

237.0 (523.0)

kg (lb)

Weight (Gross) :

247.0 (545.0)

kg (lb)
