Free Match Extreme Series

Function: Heat Pump
Capacity: 18000 BTU
Tags:
Collections:
GREE CanadaFree Match M Series
Free Match M Series
Free Match - VITA Wall-Mounted Units
GREE CanadaFree Match - VITA Wall-Mounted Units

OPTIMAL PERFORMANCE IN THE HARSHEST OF CLIMATES

Using state-of-the-art technologies, Free Match Extreme high-efficiency heat pumps provide
both powerful “ULTRA” heating and cooling in two to three separate areas. Each indoor unit
can be independently controlled to provide the right temperature for each zone.

  • IDEAL FOR THE CANADIAN CLIMATE
    Each coil on Free Match Extreme outdoor condensing units has a corrosion-
    resistant coating to ensure optimum energy efficiency in the most extreme
    climates.




Sales Brochure - French
Sales Brochure - English

System Performance

Cooling Capacity

18,000 BTU/h (6,998 – 21,001)

Heating Capacity

21,000 BTU/h (7,000 – 26,000)

Power Input :

1,450

W

Power Input :

1,710

W

SEER 2 :

20.0

BTU/W*h

HSPF 2 :

10.0

BTU/W*h

EER 2 :

12.0

BTU/W*h

COP :

3.60

W/W

Indoor Unit Specifications

Moisture Removal Capacity :

–

L/h (pt/h)

Airflow Volume :

4300 (2531)

m³/h (CFM)

Sound Pressure Level :

–

dB(A)

Dimensions :

–

mm (in)

Weight (Net) :

–

kg (lb)

Weight (Gross) :

–

kg (lb)

Outdoor Unit Specifications

Ambient Temperature Range (Cooling) :

-18 to 48 (0 to 118)

C° (F°)

Ambient Temperature Range (Heating) :

-35 to 24 (-31 to 75)

C° (F°)

Sound Pressure Level :

58

dB(A)

Dimensions :

1003 x 790 x 417 (39-31/64 x 31-7/64 x 16-13/32)

mm (in)

Weight (Net) :

78.0 (172.0)

kg (lb)

Weight (Gross) :

83.0 (183.0)

kg (lb)
