By GREE Canada

Free Match - Ceiling Cassettes

Function: Heat Pump
Capacity: 12000 BTU

The ceiling cassette offers discreet performance through an innovative design. It is suitable
for any room and can be easily installed in ceilings, leaving only a decorative grille visible.

Key Features:

■ Decorative grille (included)
■ 4-way discharge air
■ Multiple fan speed
■ Control lock
■ Swing louver control
■ Recovery after a power failure
■ Internal condensate drain pump
■ Sentry float switch
■ Washable dust filters
■ Remote controller (included)
■ Wired controller (in option)

System Performance

Cooling Capacity

12,000 BTU/h

Heating Capacity

13,000 BTU/h

Power Input :

W

Power Input :

W

SEER 2 :

BTU/W*h

HSPF 2 :

BTU/W*h

EER 2 :

BTU/W*h

COP :

W/W

Indoor Unit Specifications

Moisture Removal Capacity :

1.40 (2.96)

L/h (pt/h)

Airflow Volume :

560 / 520 / 450 (330 / 306 / 265)

m³/h (CFM)

Sound Pressure Level :

44 / 41 / 38 / 34

dB(A)

Dimensions :

595 x 595 x 241 (23-1/2 x 23-1/2 x 9-1/2)

mm (in)

Weight (Net) :

20.0 (44.1)

kg (lb)

Weight (Gross) :

24.0 (52.9)

kg (lb)

Outdoor Unit Specifications

Ambient Temperature Range (Cooling) :

C° (F°)

Ambient Temperature Range (Heating) :

C° (F°)

Sound Pressure Level :

dB(A)

Dimensions :

mm (in)

Weight (Net) :

kg (lb)

Weight (Gross) :

kg (lb)
